Specs
| Specification | Industrial Tow-Behind | ||
|---|---|---|---|
| Model | TLB25-35BV | TLB25-37CH | TLB25-49KBD |
| Engine | Briggs & Stratton® Vanguard™ BIG BLOCK™, V-Twin, electric start | Kohler® Command PRO®, V-Twin, electric start | Tier 4 Compliant Kubota®, 4-cylinder, liquid-cooled, electric start |
| HP* | 35 | 37 | 49 |
| Fuel Capacity / Tank | 8.5 gallons – plastic tank with built-in fuel gauge | 8.5 gallons – plastic tank with built-in fuel gauge | 8.5 gallons – plastic tank with built-in fuel gauge |
| CFM Output | 6,781 | 6,909 | 7,318 |
| Frame Construction | All-steel, welded | All-steel, welded | All-steel, welded |
| Impeller Construction | 4-blade, 1/2″-thick blades, all-steel, welded | 4-blade, 1/2″-thick blades, all-steel, welded | 4-blade, 1/2″-thick blades, all-steel, welded |
| Impeller Mounting | Straight bore | Straight bore | Straight bore |
| Impeller Diameter / Width | 25″ / 9″ | 25″ / 9″ | 25″ / 9″ |
| Blower Housing Construction | Removable back panel for easy impeller and wear plate access | Removable back panel for easy impeller and wear plate access | Removable back panel for easy impeller and wear plate access |
| Blower Housing Width | 10.5″ | 10.5″ | 10.5″ |
| Blower Housing Wear Plates | Standard: 1/4″-steel, replaceable | Standard: 1/4″-steel, replaceable | Standard: 1/4″-steel, replaceable |
| Intake Hose Specifications | 84″ length, 16″-diameter intake hose, 0.045 blue polyurethane rubber, wire helix with wearstrip | 84″ length, 16″-diameter intake hose, 0.045 blue polyurethane rubber, wire helix with wearstrip | 84″ length, 16″-diameter intake hose, 0.045 blue polyurethane rubber, wire helix with wearstrip |
| Unit Mounting | Hitch: at least 10,000 lb rating | Hitch: at least 10,000 lb rating | Hitch: at least 10,000 lb rating |
| Discharge Tube | Clear thermoplastic, 12″ diameter, 84″ length | Clear thermoplastic, 12″ diameter, 84″ length | Clear thermoplastic, 12″ diameter, 84″ length |
| Throttle Control | Commercial-grade, all-steel mechanicals | Commercial-grade, all-steel mechanicals | Commercial-grade, all-steel mechanicals |
| Highway Ready** | Yes – standard roadside package, including wheel chocks and cones | Yes – standard roadside package, including wheel chocks and cones | Yes – standard roadside package, including wheel chocks and cones |
| Axle | Heavy-duty Dexter Torflex® axle (3,500 lb) | Heavy-duty Dexter Torflex® axle (3,500 lb) | Heavy-duty Dexter Torflex® axle (3,500 lb) |
| Tires | 205 / 75 D15 highway tires with steel wheels | 205 / 75 D15 highway tires with steel wheels | 205 / 75 D15 highway tires with steel wheels |
| Trailer Width | 66.75″ | 66.75″ | 66.75″ |
| Accessories | Light Kit, Brake Kit | Light Kit, Brake Kit | Light Kit, Brake Kit |
| Height | 121.25″ | 121.25″ | 121.25″ |
| Weight | 1,700 lb | 1,700 lb | 2,300 lb |
| Warranty | 2-Year Commercial; 90-Day Rental | 2-Year Commercial; 90-Day Rental | 2-Year Commercial; 90-Day Rental |
| MSRP | $16,699 | $17,199 | $39,999 |
| * Engine power levels as rated by the manufacturer. All models subject to availability. ** Reference your local regulations to ensure compliance. Contact your local Scag dealer for specific availability information. | |||
